| Material | Pure titanium & Titanium alloy |
| Specification | Dia5.0-300*≤6000mm |
| state | R Y M |
| Density | 4.51g/cm3 |
| Grade | Gr1，Gr2，Gr3，Gr4，Gr5，Gr6，Gr7，Gr9，Gr11，Gr12，Gr23,etc |
Mechanical equipment, electroplating equipment, medical, various precision machine parts etc
1、High melting point, high strength and low density
2、High temperature resistance, low temperature resistance and corrosion resistance
3、Strong acid and alkali resistance
4、Low thermal conductivity
5、Good stability
Chemical Composition:| Grade | Composition A,max% (mass/mass) | ||||||||||
| N | C | H | Fe | O | Al | V | Pd | Mo | Ni | Ti | |
| Gr1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | / | / | / | / | v | Bal |
| Gr2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | / | / | Bal |
| Gr3 | 0.05 | 0.08 | 0.015 | 0.30 | 0.35 | / | / | / | / | / | Bal |
| Gr4 | 0.05 | 0.08 | 0.015 | 0.50 | 0.40 | / | / | / | / | / | Bal |
| Gr5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5-6.75 | 3.5-4.5 | / | / | / | Bal |
| Gr7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | 0.12-0.25 | / | / | Bal |
| Gr9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5-3.5 | 2.0-3.0 | / | / | / | Bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | 0.2-0.4 | 0.6-0.9 | Bal |
| Gr23 | 0.03 | 0.08 | 0.013 | 0.25 | 0.13 | 5.5-6.50 | 3.5-4.5 | / | / | / | Bal |
